Floor Mounted with Floor Brackets / No Overhead Braced Cubicle Partitioning Systems

Available in 13mm Compact Laminate and 18mm / 32mm MR Board.
Suitable for Toilet & Showers Partitions. Shower partitions available in 13mm Compact Laminate only.

No overhead bracing makes this system perfect for most low ceiling applications.


Overall Height

Overall Depth
1500mm to 1800mm

Divisional Panels
1700mm high including 205mm floor clearance

Frontal Panels
1905mm high,
minimum width 200mm, maximum 450mm

1700mm high x 600mm wide
with a 205mm floor clearance

Aqua Series Door Hardware
Available in satin chrome
or satin matte black finish

No Headrail

Floor Bracket
Clear anodised aluminium floor bracket

Wall Channels
Clear anodised aluminium U channel


Rebated Doors
Privacy profile option available

Powder Coating Option Available
To match board colour

Door Hardware
Bolt Through Hardware Available

AquaSeries Door Hardware

Clear Anodised Aluminium, Satin Finish

Black Enamel Coated, Satin Finish

Lift off spring hinges



Aqualoo cubicle partitioning systems are low maintenance, water, impact, graffiti resistant and fire retardant.

Compact laminate cubicle partitioning systems meet Group 3 Classification (in accordance with AS 5637.1-2015).

A family owned company, WCCI has been in operation since 2000 with distributors in SA, NSW, VIC and QLD – Aqualoo offer supply and install or offer flat pack options Australia Wide.
